Beta 400 Pro
Beta-400Pro is a fully automatic large-scale cutting machine, suitable for cutting various metal materials, ceramics, quartz glass, and rock samples. Beta-400Pro is equipped with various clamps to cut irregularly shaped workpieces, and it features automatic/manual feed cutting of the worktable (Y-axis), chop cutting of the cutting disc (Z-axis), and manual/automatic horizontal translation of the worktable (X-axis).
Product description
- Wheel Diameter: Φ400mm / Φ450mm
-
Rated Power: 7.5 kW
-
Maximum Cutting Diameter: Φ130mm (400mm wheel), Φ150mm (450mm wheel)
-
Cast aluminum base, 304 stainless steel cover for strength, durability, and corrosion resistance
-
Joystick control for XYZ-axis alignment, easy and quick operation
-
Large worktable and operating space
-
X-axis platform automatically moves, enabling continuous cutting
-
Equipped with an exhaust and air purification system
-
150-litre freestanding independent water tank
-
Integrated magnetic separator, paper belt filtration system, and laser alignment for clean operation and precise positioning
Specification
| Wheel Diameter | Φ400mm |
|---|---|
| Motor Power | 7.5kw |
| Wheel Speed | 800-2000rpm |
| Wheel movement | Manual / Platform Feed / Chop / Segmented / Parallel Slicing |
| Cut Types | Constant speed / Pulsing / Automatic speed adjustment |
| Vising Table Size | 438 × 388 mm |
| Max Cutting Diameter | Ф130mm(400mm Abrasive blades) |
| Max Square Cross-Section | 150x300mm(400mm Abrasive blades) |
| Travel Movement | X-axis: 200mm |
| W*D*H | 1017×1317×1729mm(Closed); 1851×1774×2224mm(Open) |
| Weight | 376kg |
