Beta 250 Pro
Automatic Abrasive Sectioning Machine
Beta-250 is a fully automatic cutting machine equipped with advanced intelligent control technology and a full-touchscreen interface. It is suitable for cutting various materials, including metals, ceramics, quartz glass, and petrographic samples. Supports fully automatic cutting withX, Y, Z, and R axes, enabling multi-section cutting with varying thicknesses and angles. (Y-axis can be manually controlled, and R-axis is an optional feature.)
Product description
- Wheel Diameter: Φ250mm;
- Rated power: 3kw;
- Maximum cutting diameter: 85mm;
- Fully automated control of X, Y, Z, and R axes. The Y-axis supports manual control, and the R-axis (rotation/angle) is an optional feature;
- Capable of holding extra-long samples extending through the side door;
- Supports multi-section continuous cutting on the X-axis (Raxis), enabling equal thickness (angle) cutting or cutting at any specified position;
- Spacious worktable and cutting chamber, with a worktable size of 280×300 mm;
- 10-inch large touchscreen;
- Equipped with a laser alignment device;
Specification
| Wheel Diameter | Φ250mm |
|---|---|
| Motor Power | 3kw |
| Wheel Speed | 1000-3500rpm |
| Wheel movement | Vertical / Horizontal / Segmented / Continuous / R-Axis Rotary Cutting (Optiona) |
| Cut Types | Constant speed / Pulsing / Automatic speed adjustment |
| Vising Table Size | 280x300mm |
| Max Cutting Diameter | Φ85mm |
| Max Square Cross-section | 85x250mm |
| Travel Movement | X-axis:100mm; Y-axis: 250mm; Z-axis:160mm; R-axis: 360° |
| WxDxH | 930x900x720mm |
| Weight | 250kg |
